IS917主控数据恢复参数如何解读？

IS917-5T538 ad de 94 eb 1×1

Layout
  IS917 1094_32 Xor 3c58_256
Mix
  Input
    Order  0
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  Serg for forum 9364

IS917 2c 64 64 3c 1×1

Layout
  IS917 1094_32 Xor 3c58_512
Mix
  Input
    Order  0
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3ff
  Actions
    Scan
Comments
  by Arvika
  MBR, FAT32 broken, need rebuild manually

IS917 2c 64 64 3c 2×1

Layout
  IS917 1094_24 Xor 3c58_512
Mix
  Input
    Order  0/1
  Join by Page
    Parts  2
    Page   0x800000
  Cross Block
    Field  Block Number
    Block  0x800000
    Parts  2
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x7ff
    Mix          2/0x4000
  Actions
    Scan
Comments
  Serg for forum 8261

IS917 2c 84 44 32 1×1

Layout
  IS917 1146_2_32 Xor f73c_128 Mod
Mix
  Input
    Order  0
  Block Pair
    Block  0x800000
    Page   0x4000
Assembler
  Block Number
    Block Size   0x1000000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3ff
  Actions
    Scan
Comments
  by Arvika
  check conflicts

IS917 2c 84 58 32 1×1

Layout
  IS917 1122_32 Xor df3c_256_192 Mod
Mix
  Input
    Order  0
  Block Pair
    Block  0xc00000
    Page   0x4000
Assembler
  Block Number
    Block Size   0x1800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x2e1
  Actions
    Scan
Comments
  by Bolo

IS917 2c 84 64 54 1×1

Layout
  IS917 1122_32 Xor f73c_128 Mod
Mix
  Input
    Order  0
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Image Cut    (0/0x18000/0x4000/0x8000/0x4000/0x8000/(0x8000/0x8000)*0x7c/0x4
000/0x8000/0x4000/0)*4
    Banks        00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  Serg for forum 11850

IS917 2c 84 64 54 1×1 v2

Layout
  IS917 1100_32 Xor f73c_128
Mix
  Input
    Order  0
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  Check Conflicts
  Perfect Recovery
  by Bolo

IS917 2c 84 64 54 1×4

Layout
  IS917 1122_32 Xor 3c58_512
Mix
  Input
    Order  0/1/2/3
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x1fff
    Mix          4/0x4000
  Actions
    Scan
Comments
  Serg for forum 9245

IS917 2c 84 64 54 2×1 Ref

Layout
  IS917 1122_32 Xor f73c_128 Mod
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x800000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x1000000
    Bank Space   0x4000
    Image Cut    0x0/0x60000/(0x10000/0x20000)*2/(0x20000)*248/0x10000/0x20000/0
x10000/0x0
    Banks        00 / 0x000 / 0x7ff
    Mix          2 / 0x8000
  Actions
    Scan
Comments
  Serg for forum 12033

IS917 2c a4 e5 3c 1×2

Layout
  IS917 1094_32 Xor f73c_128
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x800000
    Page   0x4000
  Join by Page
    Parts  2
    Page   0x8000
Assembler
  Block Number
    Block Size   0x2000000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  Serg for forum 9380

IS917 2c a4 e5 3c 2×2

Layout
  IS917 1094_32 Xor f73c_128
Mix
  Input
    Order  0/1/2/3
  Block Pair
    Block  0x800000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x1000000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x1fff
    Mix          4 / 0x8000
  Actions
    Scan
Comments
  Serg for forum 12004

IS917 2c a4 e5 54 1×2

Layout
  IS917 1122_32 Xor 3c58_512
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x800000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x1000000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0xfff
    Mix          2/0x8000
  Actions
    Scan
Comments
  Serg for forum 9407

IS917 2c a4 e5 54 1×4

Layout
  IS917 1122_32 Xor f73c_128 Mod
Mix
  Input
    Order  0/1/2/3
  Block Pair
    Block  0x800000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x1000000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x1fff
    Mix          4 / 0x8000
  Actions
    Scan
Comments
  Serg for forum 12692

  Image was not perfect

IS917 45 3a 94 93 2×1

Layout
  IS917 1094_32 Xor f73c_128 Mod
Mix
  Input
    Order  0/1
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Image Cut    0/(0x10000/0x8000/(0x8000/0x8000)*125/0x8000/0x10000)*4

    Banks        00 / 0x000 / 0x1fff
    Mix          2 / 0x4000
  Actions
    Scan
Comments
  Serg for forum 11279

IS917 45 3a 95 83 2×2

Layout
  IS917 1100_32 Xor f73c_128 v2
Mix
  Input
    Order  2/3/0/1
  Block Pair
    Block  0x200000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3fff
    Mix          4 / 0x8000
  Actions
    Scan
Comments
  by Arvika
  check conflicts
  chip order can be other

IS917 45 3a a4 93 2×1

Layout
  IS917 1094_32 Xor f73c_128
Mix
  Input
    Order  1/0
  Block Pair
    Block  0x400000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0xfff
    Mix          2/0x8000
  Actions
    Scan
Comments
  Serg for forum 9219

IS917 45 3a a5 82 1×2

Layout
  IS917 1094_32 Xor 3c58_256
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x200000
    Page   0x2000
  Block Pair
    Block  0x200000000
    Page   0x400000
  Join by Page
    Parts  2
    Page   0x800000
  Cross Block
    Field  Block Number
    Block  0x400000
    Parts  4
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x1fff
    Mix          4/0x4000
  Actions
    Scan
Comments
  Serg for forum 10017

IS917 45 3a a5 82 1×4

Layout
  IS917 1094_32 Xor 3c58_256
Mix
  Input
    Order  0/1/2/3
  Block Pair
    Block  0x200000
    Page   0x2000
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3fff
    Mix          4/0x4000
  Actions
    Scan
Comments
  Serg for forum 9100

IS917 45 3a a5 82 1×4 v2

Layout
  IS917 1094_32 Xor 3c58_256
Mix
  Input
    Order  0/1/2/3
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x200000
    Bank Space   0x40000
    Banks        00 / 0x000 / 0x7fff
    Mix          4/0x2000
  Actions
    Scan
Comments
  by Serg

IS917 45 3a a5 82 2×2

Layout
  IS917 1094_32 Xor 3c58_256
Mix
  Input
    Order  2/3/0/1
  Block Pair
    Block  0x200000
    Page   0x2000
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3fff
    Mix          4/0x4000
  Actions
    Scan
Comments
  Serg for forum 10115
  Dump order can be other

IS917 45 3e 87 93 1×1

Layout
  IS917 1100_32 Xor f73c_256 Mod v2
Mix
  Input
    Order  0
  Block Pair
    Block  0x82c000000
    Page   0x400000
  Cross Block
    Field  Block Number
    Block  0x400000
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x40000
    Banks        00 / 0x000 / 0x4160
    Mix          2 / 0x4000
  Actions
    Scan
Comments
  by Serg & Bolo
  Check Conflicts !
  Perfect Recovery !

IS917 45 3e 97 93 1×1

Layout
  IS917 1100_32 Xor f73c_256 Mod v2
Mix
  Input
    Order  0
  Block Pair
    Block  0x400000
    Page   0x4000
  Block Pair
    Block  0x800000000
    Page   0x800000
  Cross Block
    Field  Block Number
    Block  0x800000
    Parts  2
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x1fff
    Mix          2 / 0x8000
  Actions
    Scan
Comments
  Serg for forum 10877

IS917 45 4c 98 a3 1×1

Layout
  IS917 1122_32 Xor df3c_256_192 Mod
Mix
  Input
    Order  0
  Cut Bad Bytes
  Block Pair
    Block  0x600000
    Page   0x4000
Assembler
  Block Number
    Block Size   0xc00000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x4ff
  Actions
    Scan
Comments
  by Arvika

IS917 45 4c 98 a3 1×2

Layout
  IS917 1142_32 Xor df3c_256
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x600000
    Page   0x4000
  Join by Page
    Parts  2
    Page   0xc00000
  Cross Block
    Field  Block Number
    Block  0xc00000
    Parts  2
Assembler
  Block Number
    Block Size   0xc00000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0xb4a
    Mix          2/0x8000
  Actions
    Scan
Comments
  Serg for forum 9525

  Developer notes:
  Cross block used because
  number of blocks in dump is odd
  and Cross Bank do not work

IS917 45 4c 98 a3 2×1

Layout
  IS917 1122_32 Xor df3c_256_192 Mod
Mix
  Input
    Order  0/1
  Software Bad Bytes
    Block  384
    Group  2
  Block Insert
    Block  0x600000
    At     0xb4b
  Block Pair
    Block  0x600000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0xc00000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0xb4a
    Mix          2/0x8000
  Actions
    Scan
Comments
  Serg for forum 10780
  Use Block Insert because
  dump have odd (0xb4b) number of 0x600000 blocks

IS917 45 de 94 83 1×2

Layout
  IS917 1094_32 Xor f73c_128 Mod
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x200000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Image Cut    0/(0x20000/0x10000/(0x10000/0x10000)*61/0x10000/0x20000)*4

    Banks        00 / 0x000 / 0xfff
    Mix          2 / 0x8000
  Actions
    Scan
Comments
  Serg for forum 10773

IS917 45 de 94 93 1×1

Layout
  IS917 1100_32 Xor f73c_128
Mix
  Input
    Order  0
  Block Pair
    Block  0x400000
    Page   0x4000
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3ff
  Actions
    Scan
Comments
  Serg for forum 8238

IS917 45 de 94 93 1×1 v2

Layout
  IS917 1094_32 Xor 3c58_256
Mix
  Input
    Order  0
  Block Pair
    Block  0x400000
    Page   0x4000
Assembler
  Block Number
    Block Size   0x800000
    Banks        00 / 0x000 / 0x3ff
  Actions
    Scan
Comments
  by Arvika
  check conflicts

IS917 45 de 94 93 1×1 v3

Layout
  IS917 1100_32 Xor f73c_128
Mix
  Input
    Order  0
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  Serg for forum 9633

IS917 45 de 94 93 1×1 v4

Layout
  IS917 1094_32 Xor f73c_128 Mod
Mix
  Input
    Order  0
  Block Pair
    Block  0x400000
    Page   0x4000
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3ff
  Actions
    Scan
Comments
  Serg for forum 10768

IS917 45 de 94 93 1×4

Layout
  IS917 1094_32 Xor f73c_128 Mod
Mix
  Input
    Order  0/1/2/3
  Block Pair
    Block  0x400000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0xfff
    Mix          4/0x8000
  Actions
    Scan
Comments
  by Arvika
  MBR, FAT erased. Dirs aligned.
  Save image, scan by any soft

IS917 89 84 64 3c 1×1

Layout
  IS917 1094_32 Xor f73c_128
Mix
  Input
    Order  0
  Block Pair
    Block  0x800000
    Page   0x4000
Assembler
  Block Number
    Block Size   0x1000000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3ff
  Actions
    Scan
Comments
  Serg for forum 9878

IS917 89 84 64 3c 2×1

Layout
  IS917 1094_32 Xor 3c58_512
Mix
  Input
    Order  1/0
  Block Pair
    Block  0x800000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x1000000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x7ff

    Mix          2/0x8000
  Actions
    Scan
Comments
  Serg for forum 8732

IS917 89 84 64 3c 2×1 v2

Layout
  IS917 1094_32 Xor 3c58_512
Mix
  Input
    Order  0/1
  Join by Page
    Parts  2
    Page   0x800000
  Cross Block
    Field  Block Number
    Block  0x800000
    Parts  2
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0xfff
    Mix          2/0x4000
  Actions
    Scan
Comments
  by Arvika
  check conflicts

IS917 89 84 64 3c 2×1 v3

Layout
  IS917 1094_32 Xor f73c_128
Mix
  Input
    Order  1/0
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0xfff
    Mix          2 / 0x4000
  Actions
    Scan
Comments
  Serg for forum 11516

IS917 89 88 24 4b 1×4

Layout
  IS917 1072_32 Xor f73c_128
Mix
  Input
    Order  0/1/2/3
  Block Pair
    Block  0x200000
    Page   0x2000
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x1fff
    Mix          4 / 0x4000
  Actions
    Scan
Comments
  Serg for forum 11181

IS917 89 a4 64 32 1×2

Layout
  IS917 1146_2_32 Xor f73c_256 Mod
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x1000000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x2000000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x7ff
    Mix          2/0x8000
  Actions
    Scan
Comments
  Serg for forum 10586

IS917 89 a4 64 32 2×1

Layout
  IS917 1146_2_32 Xor f73c_128
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x1000000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x2000000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x7ff
    Mix          2/0x8000
  Actions
    Scan
Comments
  by Arvika
  check conflicts

IS917 89 a8 25 cb 1×4

Layout
  IS917 1072_32 Xor 3c58_256
Mix
  Input
    Order  0/1/2/3
  Block Pair
    Block  0x200000
    Page   0x2000
  Join by Page
    Parts  4
    Page   0x400000
  Cross Block
    Field  Block Number
    Block  0x400000
    Parts  4
Assembler
  Block Number
    Block Size   0x400000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x3fff
    Mix          4/0x4000
  Actions
    Scan
Comments
  Serg for forum 8575

IS917 98 3a 94 93 1×1

Layout
  IS917 1094_32 Xor f73c_128 Mod
Mix
  Input
    Order  0
  Block Pair
    Block  0x400000
    Page   0x4000
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Image Cut    (0/0x10000/0x8000/(0x8000/0x8000)*125/0x8000/0x10000/0)*4
    Banks        00 / 0x000 / 0x7ff
  Actions
    Scan
Comments
  Serg for forum 11249

IS917 98 3a 94 93 2×1

Layout
  IS917 1094_32 Xor f73c_128
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x400000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0xfff
    Mix          2 / 0x8000
  Actions
    Scan
Comments
  Serg for forum 10700

IS917 98 de 94 93 1×4

Layout
  IS917 1100_32 Xor f73c_128 Mod
Mix
  Input
    Order  0/1/2/3
  Block Pair
    Block  0x400000
    Page   0x4000
  Cross Dump
    Field  Block Number
    Parts  4
    Step   1
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x9ff
    Mix          4 / 0x8000
  Actions
    Scan
Comments
  by Arvika
  check conflicts

IS917 b5 64 64 54 2×1

Layout
  IS917 1122_32 Xor 3c58_512
Mix
  Input
    Order  0/1
  Cross Dump
    Field  Block Number
    Parts  2
    Step   1
Assembler
  Block Number
    Block Size   0x800000
    Bank Space   0x4000
    Banks        00 / 0x000 / 0x7ff
    Mix          2 / 0x4000
  Actions
    Scan
Comments
  Serg for forum 11171

常见问题解答

IS917主控的ID 94 EB和2C 64 64 3C分别代表什么？

IS917主控的ID 94 EB和2C 64 64 3C是闪存颗粒的识别码（Flash ID）。94 EB通常对应某款1×1 nm工艺的闪存，而2C 64 64 3C是另一款闪存的ID。这些ID在数据恢复中用于确定闪存的类型、容量和通道配置，从而匹配正确的提取算法和布局参数，是Flash Extractor工具进行底层数据读取的关键依据。

IS917的Xor 3c58_256和Xor 3c58_512有什么区别？

Xor 3c58_256和Xor 3c58_512是IS917主控的XOR（异或）算法变体，区别在于XOR操作的数据块大小。256表示按256字节块进行异或处理，512则按512字节块处理。这种差异源于闪存页大小或ECC配置不同。在数据恢复时，必须选择正确的XOR值，否则读取的数据会因解扰错误而无法重组，导致恢复失败。

IS917的MBR和FAT32损坏时如何手动重建？

当IS917设备的MBR和FAT32损坏时，手动重建需先用Flash Extractor提取完整的原始镜像，然后分析分区表起始位置和FAT表结构。由于FAT32的根目录和簇链信息可能残留，可通过搜索文件签名（如JPEG头）定位数据区，再根据FAT表项重建目录和文件分配。建议使用工具中的Assembler功能，按Block Number和Bank Space参数重新组织数据，最后修复引导扇区。

专业数据恢复，值得信赖

闪存芯片数据恢复，专业之选

芯片级恢复，精准高效

Oracle 数据库精准恢复

取证级数据提取

全球数据恢复实验室与取证团队的信赖之选

企业级数据安全保障

立即体验专业数据恢复工具

常见问题解答

IS917主控的ID 94 EB和2C 64 64 3C分别代表什么？

IS917的Xor 3c58_256和Xor 3c58_512有什么区别？

IS917的MBR和FAT32损坏时如何手动重建？

发表回复取消回复

需要专业数据恢复工具？

专业数据恢复，值得信赖

闪存芯片数据恢复，专业之选

芯片级恢复，精准高效

Oracle 数据库精准恢复

取证级数据提取

全球数据恢复实验室与取证团队的信赖之选

企业级数据安全保障

立即体验专业数据恢复工具

IS917主控数据恢复参数如何解读？

常见问题解答

IS917主控的ID 94 EB和2C 64 64 3C分别代表什么？

IS917的Xor 3c58_256和Xor 3c58_512有什么区别？

IS917的MBR和FAT32损坏时如何手动重建？

发表回复 取消回复

相关文章

需要专业数据恢复工具？

发表回复取消回复
