| FC8508-10 2c 68 01 a6 1×2 |
|
Layout
AU6983 538
Mix
Input
Order 0/1
Join by Dump
Parts 2
Assembler
Block Number
Block Size 0x80000
Bank Space 0x400
Actions
Scan
Find Bank Size
Comments
Serg for forum 5915
Layout
AU6983 538
Mix
Block Cut
Block 0x100000/0x100000
Block Cut
Block 0/0x19000/0x1000/0x3000/0x1000/0x3000/0x1000/0x3000/0x1000/0x3000/0x1
000/0x3000/0x1000/0x3000/0x1000/0x3000/0x1000/0x2000/0x2000/0x3000/0x1000/0x200
0/0x2000/0x2000/0x2000/0x2000/0x2000/0x2000/0x2000/0x2000/0x2000/0x1000/0x3000/
0x1000/0x3000/0x1000/0x3000/0x1000/0x7000/0x1000/0x7000/0x1000/0x3B000/0x2000/0
x4000/0x2000/0xc000/0x2000/0x2000/0x8000/0x2000/0x2000/0x24000/0x2000/0x2000/0xa000
Assembler
Block Number
Block Size 0xa1000
Bank Space 0x800
Banks
0 / 0 / 0x800
Actions
Scan
| FC8508 2c 68 04 46 1×1 v2 |
|
Layout
AU6983 538
Mix
Input
Order 0
Assembler
Block Number
Block Size 0x100000
Bank Space 0x400
Banks
00 / 0x000 / 0x3e9
01 / 0x000 / 0x1f3
02 / 0x000 / 0x3f3
03 / 0x000 / 0x3f8
Actions
Scan
Comments
Vladus 14.01.2011 from forum 3603 case
Need Bank Size correction
Layout
AU6983 538
Mix
Input
Order 0/1
Join by Dump
Parts 2
Assembler
Block Number
Block Size 0x100000
Bank Space 0x400
Banks 00 / 0x000 / 0x3dd
01 / 0x000 / 0x3f3
02 / 0x000 / 0x3f3
03 / 0x000 / 0x3f3
04 / 0x000 / 0x3f3
05 / 0x000 / 0x3f3
06 / 0x000 / 0x3f3
07 / 0x000 / 0x3f3
08 / 0x000 / 0x3f1
09 / 0x000 / 0x3f3
Actions
Scan
Comments
by Vlad cs 662
bank size correction perfect recovery
Layout
AU6983 538
Mix
Input
Order 0
Assembler
Block Number
Block Size 0x100000
Bank Space 0x400
Actions
Scan
Find Bank Size
Comments
By aj2008
100% recovered after check dirs command
Layout
AU6983 538
Mix
Input
Order 0
Assembler
Block Number
Block Size 0x80000
Bank Space 0x400
Banks
00 / 0x000 / 0x3e5
01 / 0x000 / 0x3f3
02 / 0x000 / 0x3f3
03 / 0x000 / 0x3f3
04 / 0x000 / 0x3f3
05 / 0x000 / 0x3f3
06 / 0x000 / 0x3ea
07 / 0x000 / 0x3f3
Actions
Scan
Comments
Vladus 02.03.2011 from customer service 501 case
Need Bank Size correction
| FC8508 89 d7 94 3e 1×1 Ref |
|
Layout
AU6983 538
Mix
Input
Order 0
Block Cut
Block 0x16000/0x1000/0x69000
Assembler
Block Number
Block Size 0x7f000
Bank Space 0x400
Actions
Scan
Find Bank Size
Comments
Serg for forum 10530
Layout
FC8508 534 Xor 6771_128
Mix
Assembler
Block Number
Block Size 0x100000
Bank Space 0x400
Actions
Scan
Find Bank Size
Comments
Serg for forum 3794
100% recovery
There was only 1 bank, i dont sure about bank space & size
| FC8508 98 d5 94 32 1×1 fake |
|
Layout
AU6986 528
Mix
Input
Order 0
Block Cut
Block (4096/1024/3072/0)*2/(0/8192/4096/1024/3072/0)*62/0/16384
Assembler
Block Number
Block Size 0x70000
Bank Space 0x400
Actions
Scan
Find Bank Size
Comments
Vladus 14.03.2011 from forum 3851 case
Perfect recovery
| FC8508 98 d5 94 32 1×1 v2 |
|
Layout
AU6986 528
Mix
Input
Order 0
Block Cut
Block 0x2c000/0x2000/0x4c000/0x2000/0x12000/0x2000/0x1c000/0x2000/0x12000/0
x2000/0x2a000/0x2000/0xa000/0x2000/0x6000/0
Assembler
Block Number
Block Size 0xf2000
Bank Space 0x400
Banks 00 / 0x000 / 0x3d8
01 / 0x000 / 0x3d8
Actions
Scan
Comments
By Vladus via Teamviewer
Perfect Recovery
| FC8508 98 d5 94 32 1×1 v3 |
|
Layout
AU6986 528
Mix
Input
Order 0
Assembler
Block Number
Block Size 0x100000
Bank Space 0x400
Actions
Scan
Find Bank Size
Comments
By Arvika
100% recovered
Layout
AU6986 528
Mix
Assembler
Block Number
Block Size 0x200000
Bank Space 0x400
Actions
Scan
Find Bank Size
Comments
Vladus 31.01.2011 from forum case 3683
Red areas in dump - uncorrectable ECC
