IS903-D6SJC 89 88 24 4b 2x1 |
|
28Rflash extractor
Layout
IS903 1100_30 Xor 49c1_256
Mix
Input
Order 0/1
Block Pair
Block 0x200000
Page 0x2000
Cross Dump
Field Block Number
Parts 2
Step 1
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Mix 2/0x4000
Actions
Scan
Comments
Serg for forum 9369 |
28Rflash extractor28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256
Mix
Input
Order 0/1
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 2
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
By Arvika
check conflicts
Layout
IS903 1094_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1/4/5/2/3/6/7
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 8/0x8000
Actions
Scan
Comments
by Serg
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512
Mix
Input
Order 0/1
Block Pair
Block 0x800000
Page 0x4000
Join by Page
Parts 2
Page 0x1000000
Cross Block
Field Block Number
Block 0x1000000
Parts 2
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Mix 2/0x8000
Actions
Scan
Comments
Serg for forum 7596
28Rflash extractor28Rflash extractor
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512
Mix
Input
Order 0/1/3/2
Block Pair
Block 0x800000
Page 0x4000
Join by Page
Parts 4
Page 0x8000
Assembler
Block Number
Block Size 0x4000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3ff
Actions
Scan
Comments
Serg for forum 8245
28Rflash extractor
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1/3/2
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 4
Step 1
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Mix 4/0x8000
Actions
Scan
Comments
Serg for forum 9618
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x800000
Page 0x4000
Join by Page
Parts 8
Page 0x8000
Assembler
Block Number
Block Size 0x8000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3ff
Actions
Scan
Comments
Serg for forum 9509
Layout
IS903 1094_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1/6/7/9/8/15/14/4/5/2/3/13/12/11/10
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 8
Step 1
Join by Dump
Parts 2
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
Actions
Scan
Comments
by Serg
chip order can be other
but banks order is verified
28Rflash extractor28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1/6/7/9/8/15/14/4/5/2/3/13/12/11/10
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 8
Step 1
Join by Dump
Parts 2
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
Actions
Scan
Comments
by Serg
chip order can be other
but banks order is verified
28Rflash extractor
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1/2/3
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 4
Step 1
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Mix 4 / 0x8000
Actions
Scan
Comments
Serg for forum 9930
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_512 v5
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 4
Step 1
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Mix 4/0x8000
Actions
Scan
Comments
Serg for forum 8971
28Rflash extractor
Layout
IS903 1076_30 I Xor 3c46_128
Mix
Input
Order 4/0/5/1/6/2/7/3
Block Pair
Block 0x100000
Page 0x2000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x200000
Bank Space 0x8000
Banks 00 / 0x000 / 0x7fff
Mix 8/0x4000
Actions
Scan
Comments
Serg for forum 8868
28Rflash extractor
Layout
IS903 1076_30 I Xor 3c46_128
Mix
Input
Order 4/5/6/7/1/0/3/2
Block Pair
Block 0x100000
Page 0x2000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x200000
Bank Space 0x8000
Banks 00 / 0x000 / 0x7fff
Mix 8/0x4000
Actions
Scan
Comments
Serg for forum 11003
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v4
Mix
Input
Order 0/1/2/3
Block Pair
Block 0x800000
Page 0x4000
Join by Page
Parts 4
Page 0x1000000
Cross Block
Field Block Number
Block 0x1000000
Parts 4
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4 /0x8000
Actions
Scan
Comments
Serg for forum 8011
|
|
|
|
|
|
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x800000
Page 0x4000
Join by Page
Parts 8
Page 0x1000000
Cross Block
Field Block Number
Block 0x1000000
Parts 8
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
Actions
Scan
Comments
Serg for forum 8538
|
28Rflash extractor28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v4
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x800000
Page 0x4000
Join by Page
Parts 8
Page 0x1000000
Cross Block
Field Block Number
Block 0x1000000
Parts 8
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
Actions
Scan
Comments
by Arvika
check conflicts
|
28Rflash extractor28Rflash extractor28Rflash extractor
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
Actions
Scan
Comments
Serg for forum 10326
28Rflash extractor28Rflash extractor
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_512 v6
Mix
Input
Order 0/1/2/3
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 4
Step 1
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4/0x8000
Actions
Scan
Comments
Serg for forum 9309
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1/2/3/4/5/6/7
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x800000
Bank Space 0x40000
Banks 00 / 0x000 / 0x7fff
Mix 8 / 0x4000
Actions
Scan
Comments
by Arvika
check conflicts
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_512 v6
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x40000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
Actions
Scan
Comments
Serg for forum 10353
Layout
IS903 1100_30 I Xor 3c46_512 v5
Mix
Input
Order 4/5/6/7/1/0/3/2
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x800000
Bank Space 0x40000
Banks 00 / 0x000 / 0x7fff
Mix 8 / 0x4000
Actions
Scan
Comments
Serg for forum 10562
28Rflash extractor
Layout
IS903 1076_30 I Xor 3c46_256
Mix
Input
Order 2/0/3/1
Block Pair
Block 0x200000
Page 0x2000
Cross Dump
Field Block Number
Parts 4
Step 1
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 4 / 0x4000
Actions
Scan
Comments
Serg for forum 11341
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256
Mix
Input
Order 0/1
Block Pair
Block 0x400000
Page 0x4000
Cross Dump
Field Block Number
Parts 2
Step 1
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Mix 2 / 0x8000
Actions
Scan
Comments
Serg for forum 11561 |
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x400000
Page 0x4000
Cross Dump
Field Block Number
Parts 4
Step 1
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4/0x8000
Actions
Scan
Comments
Serg for forum 9200
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256
Mix
Input
Order 0
Block Pair
Block 0x400000
Page 0x4000
Block Pair
Block 0x840000000
Page 0x800000
Cross Block
Field Block Number
Block 0x800000
Parts 2
Step 1
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 2 / 0x8000
Actions
Scan
Comments
by Serg & Arvika
check conflicts
|
|
|
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256
Mix
Input
Order 1/0
Join by Page
Parts 2
Page 0x200000
Block Pair
Block 0x1000000000
Page 0x400000
Cross Block
Field Block Number
Block 0x200000
Parts 4
Assembler
Block Number
Block Size 0x200000
Bank Space 0x10000
Banks 00 / 0x000 / 0x10000
Mix 4/0x2000
Actions
Scan
Comments
Serg for forum 8391
|
|
|
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1
Block Pair
Block 0x800000
Page 0x4000
Join by Page
Parts 2
Page 0x8000
Assembler
Block Number
Block Size 0x2000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1ff
Actions
Scan
Comments
Serg for forum 9899
|
|
|
|
|
|
28Rflash extractor
Layout
IS903 1076_30 I Xor 3c46_128
Mix
Input
Order 0/1
Block Pair
Block 0x100000
Page 0x2000
Join by Page
Parts 2
Page 0x200000
Cross Block
Field Block Number
Block 0x200000
Parts 2
Assembler
Block Number
Block Size 0x200000
Bank Space 0x4000
Banks 00 / 0x000 / 0xfff
Mix 2 / 0x4000
Actions
Scan
Comments
Serg for forum 7051
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1/2/3/4/5/6/7
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 4
Step 1
Join by Dump
Parts 2
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4 / 0x8000
Actions
Scan
Comments
Serg for forum 10214
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v2
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 8/0x8000
Actions
Scan
Comments
Serg for forum 8943
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v5
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x800000
Page 0x4000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x1000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 8 / 0x8000
Actions
Scan
Comments
Serg for forum 9799
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v3
Mix
Input
Order 4/5/6/7/1/0/3/2
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x4000
Actions
Scan
Comments
Serg for forum 11900
28Rflash extractor
Layout
IS903 1094_30 I Xor 3c46_512 v6
Mix
Input
Order 4/5/6/7/1/0/3/2
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x4000
Actions
Scan
Comments
Serg for forum 12011
28Rflash extractor
Layout
IS903 1076_30 I Xor 3c46_256
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x200000
Page 0x2000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8 / 0x4000
Actions
Scan
Comments
Serg for forum 11012
28Rflash extractor
Layout
IS903 1100_30 Xor 49c1_256
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 4
Page 0x400000
Cross Block
Field Block Number
Block 0x400000
Parts 4
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4/0x4000
Actions
Scan
Comments
Serg for forum 7697
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x200000
Page 0x2000
Cross Dump
Field Block Number
Parts 4
Step 1
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4 / 0x4000
Actions
Scan
Comments
by Arvika
check conflicts
Layout
IS903 1076_30 Xor c1f6_256
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 8
Page 0x4000
Assembler
Block Number
Block Size 0x2000000
Bank Space 0x4000
Banks 00 / 0x000 / 0x7ff
Actions
Scan
Comments
Serg for forum 6702
28Rflash extractor
Layout
IS903 1076_30 I Xor 3c46_256
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 8
Page 0x400000
Cross Block
Field Block Number
Block 0x400000
Parts 8
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x4000
Actions
Scan
Comments
Serg for forum 7452
28Rflash extractor
Layout
IS903 1076_30 I Xor 3c46_256
Mix
Input
Order 4/5/6/7/1/0/3/2
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 8
Page 0x400000
Cross Block
Field Block Number
Block 0x400000
Parts 8
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x4000
Actions
Scan
Comments
Serg for forum 8002
28Rflash extractor
Layout
IS903 1076_30 I Xor 3c46_256
Mix
Input
Order 5/4/7/6/0/1/2/3
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 8
Page 0x400000
Cross Block
Field Block Number
Block 0x400000
Parts 8
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x4000
Actions
Scan
Comments
Serg for forum 8400
28Rflash extractor
Layout
IS903 1076_30 I Xor 3c46_256
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x200000
Page 0x2000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8 / 0x4000
Actions
Scan
Comments
Serg for forum 9075
Layout
IS903 1076_30 I Xor 3c46_256
Mix
Input
Order 0/1/3/2
Block Pair
Block 0x200000
Page 0x2000
Cross Dump
Field Block Number
Parts 4
Step 1
Assembler
Block Number
Block Size 0x400000
Bank Space 0x40000
Banks 00 / 0x000 / 0x7fff
Mix 4 / 0x4000
Actions
Scan
Comments
by Serg
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256
Mix
Input
Order 0/2/1/3
Join by Page
Parts 4
Page 0x400000
Cross Block
Field Block Number
Block 0x400000
Parts 4
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4/0x4000
Actions
Scan
Comments
Serg for forum 8613 |
28Rflash extractor28Rflash extractor
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256 v7
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x200000
Page 0x2000
Cross Dump
Field Block Number
Parts 8
Step 1
Assembler
Block Number
Block Size 0x400000
Bank Space 0x40000
Banks 00 / 0x000 / 0x410f
Mix 8 / 0x8000
Actions
Scan
Comments
Serg for forum 12499
28Rflash extractor28Rflash extractor
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x400000
Page 0x4000
Join by Page
Parts 8
Page 0x800000
Cross Block
Field Block Number
Block 0x800000
Parts 8
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
28Rflash extractor
Layout
IS903 1100_30 I Xor 3c46_256
Mix
Input
Order 0/1/2/3/5/4/7/6
Block Pair
Block 0x400000
Page 0x4000
Join by Page
Parts 8
Page 0x800000
Cross Block
Field Block Number
Block 0x800000
Parts 8
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Image Cut 0x0/(0x100000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0
x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/
0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000
/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x8000
0/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x800
00/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80
000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x8
0000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x
80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0
x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/
0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000
/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x8000
0/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x80000/0x100000)*6
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
Actions
Scan
Comments
Serg for forum 8136
ECC map was 95% green
Can not check image
Actions
Scan
Comments
Serg for forum 7784
I think dump order is totaly wrong
28Rflash extractor28Rflash extractor
|
|
|
|
28Rflash extractor
Layout
IS903 1100_30 I Xor eaa0_256 v2
Mix
Input
Order 4/5/6/7/1/0/3/2
Block Pair
Block 0x400000
Page 0x4000
Join by Page
Parts 8
Page 0x800000
Cross Block
Field Block Number
Block 0x800000
Parts 8
Assembler
Block Number
Block Size 0x800000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
Actions
Scan
Comments
Serg for forum 8461 |
|
|
28Rflash extractor
28Rflash extractor
Layout
IS903 1100_30 Xor 49c1_256
Mix
Input
Order 0/1
Block Pair
Block 0x200000
Page 0x2000
Join by Page
Parts 2
Page 0x4000
Assembler
Block Number
Block Size 0x800000
Bank Space 0x400
Banks 00 / 0x000 / 0x3ff
Actions
Scan
Comments
Serg for forum 6691 |
28Rflash extractor28Rflash extractor28Rflash extractor
28Rflash extractor
Layout
IS903 1100_30 I Xor 0040_128
Mix
Input
Order 2/3/1/0
Block Pair
Block 0x100000
Page 0x2000
Block Pair
Block 0x200000
Page 0x4000
Cross Dump
Field Block Number
Parts 4
Step 1
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4 / 0x8000
Actions
Scan
Comments
Serg for forum 10929
28Rflash extractor
Layout
IS903 1100_30 Xor 49c1_128
Mix
Input
Order 0/2/1/3
Block Pair
Block 0x100000
Page 0x2000
Join by Page
Parts 4
Page 0x200000
Cross Block
Field Block Number
Block 0x200000
Parts 4
Assembler
Block Number
Block Size 0x200000
Bank Space 0x4000
Banks 00 / 0x000 / 0x1fff
Mix 4 / 0x4000
Actions
Scan
Comments
Serg for forum 6323
ECC is not hacked for this layout
Layout
IS903 1100_30 Xor 49c1_128
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x100000
Page 0x2000
Join by Page
Parts 8
Page 0x200000
Cross Block
Field Block Number
Block 0x200000
Parts 8
Assembler
Block Number
Block Size 0x200000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x4000
Actions
Scan
Comments
Serg for forum 6920
Layout
IS903 1100_30 Xor c1f6_128
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x100000
Page 0x2000
Join by Page
Parts 8
Page 0x200000
Cross Block
Field Block Number
Block 0x200000
Parts 8
Assembler
Block Number
Block Size 0x200000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x4000
Actions
Scan
Comments
By Arvika
check conflicts
28Rflash extractor28Rflash extractor28Rflash extractor28Rflash extractor28Rflash extractor28Rflash extractor
28Rflash extractor
Layout
IS903 1100_30 Xor c1f6_128
Mix
Input
Order 0/4/1/5/2/6/3/7
Block Pair
Block 0x100000
Page 0x2000
Block Pair
Block 0x200000
Page 0x4000
Join by Page
Parts 8
Page 0x400000
Cross Block
Field Block Number
Block 0x400000
Parts 8
Assembler
Block Number
Block Size 0x400000
Bank Space 0x4000
Banks 00 / 0x000 / 0x3fff
Mix 8/0x8000
Actions
Scan
Comments
Serg for forum 7322
Alot of conflicts
Some files is OK
Some files is was broken because of conflicts
But auto conflicts works too much time
